Authentication Methods

OAuth

  • Allows apps to get information from user’s account without password
  • Uses bearer token type

Basic Access Authentication

JWT Token

  • Uses HTTP headers like Referer and Origin to reject requests from unauthorized sources
  • JWT Explanation

OAuth Authorization Code Grant Flow

Simple Flow Overview

  1. User initiates Google login from a client app
  2. App server generates authorizeUrl and sends to client
  3. Client opens authorizeUrl in browser
  4. User logs in to Google in browser
  5. Browser redirects to redirect_url (app server URL)
  6. App server receives code and state via redirect_url
  7. App server requests access token from Google using code and state
  8. Access Google resources with accessToken

Detailed Flow

Step 1: App Request to Server

The app sends OAuth authentication request to app server via web browser with:

  • Server URL: If modified by attacker, requests could go to attacker’s server
  • OAuth Server Name: (Google, Facebook, etc.)
  • Redirection URL: Deep link defined by app
  • Platform: Deep link behavior varies by platform
  • Package Name: Required for Android deep links

Security Warning

When logging in, users should check:

  • Which site is requesting OAuth
  • What permissions are being requested

Step 2-3: Server Processes Request

  • providerLookup is called to get OAuth2ServerSettings
  • urlProvider sets where to receive results after Google auth (server URL + required queries)
  • Server sends 302 redirect to Google’s authorizeUrl

Step 4-6: Authentication Flow

  • User logs in to Google
  • Client receives code + status
  • Server includes redirect_uri when redirecting to Google
  • After login, Google redirects client to that URI

Step 7-8: Token Exchange

  • Client sends status + code to redirected app server
  • App server requests access token from accessTokenUrl
  • Server creates principal containing access token

Step 9: Profile Retrieval

  • Call https://www.googleapis.com/userinfo/v2/me with access token
  • Get user’s unique ID from profile info
  • OAuth login complete

Step 10: Service Token

  • Send redirect response to client with service token

InstalledAppFlow

First Run

  • Google login window appears for authentication
  • After authentication, Access Token and Refresh Token are saved to token.json

Subsequent Runs

  • If Access Token in token.json is valid, use it
  • If expired, request new Access Token using Refresh Token
