Hibernate/JPA - Java ORM 프레임워크
Hibernate는 Java의 대표적인 ORM(Object-Relational Mapping) 프레임워크이며, JPA(Java Persistence API)의 구현체입니다.
Annotation 기반 설정
기본 엔티티 어노테이션
@Entity
@Table(name= "emp500")
public class Employee {
@Id
private int id;
private String firstName, lastName;
}
@Entity- 클래스를 엔티티로 표시@Table- 테이블명 지정 (미지정시 클래스명 사용)@Column- 컬럼명 지정 (미지정시 필드명 사용)@Id- Primary Key 지정@GeneratedValue- Primary Key 자동 생성 전략
Named Query
의미 있는 이름으로 쿼리를 정의합니다.
@NamedQueries({
@NamedQuery(
name = "findEmployeeByName",
query = "from Employee e where e.name = :name"
)
})
class Employee {}
상속 매핑
Single Table 전략
모든 클래스가 하나의 테이블에 저장됩니다.
Parent 클래스:
@Entity
@Table(name = "employee101")
@Inheritance(strategy=InheritanceType.SINGLE_TABLE)
@DiscriminatorColumn(name="type", discriminatorType=DiscriminatorType.STRING)
@DiscriminatorValue(value="employee")
public class Employee {
@Id
@GeneratedValue(strategy=GenerationType.AUTO)
@Column(name = "id")
private int id;
@Column(name = "name")
private String name;
}
SubClass:
@Entity
@DiscriminatorValue("regularemployee")
public class Regular_Employee extends Employee {
@Column(name="salary")
private float salary;
@Column(name="bonus")
private int bonus;
}
Table Per Class 전략
서브 테이블이 부모 클래스의 컬럼도 포함합니다.
Parent 클래스:
@Entity
@Table(name = "employee102")
@Inheritance(strategy = InheritanceType.TABLE_PER_CLASS)
public class Employee {
@Id
@GeneratedValue(strategy=GenerationType.AUTO)
@Column(name = "id")
private int id;
@Column(name = "name")
private String name;
}
SubClass:
@Entity
@Table(name="regularemployee102")
@AttributeOverrides({
@AttributeOverride(name="id", column=@Column(name="id")),
@AttributeOverride(name="name", column=@Column(name="name"))
})
public class Regular_Employee extends Employee {
@Column(name="salary")
private float salary;
@Column(name="bonus")
private int bonus;
}
Joined 전략
각 클래스별로 테이블이 생성되고 조인으로 조회합니다.
Parent 클래스:
@Entity
@Table(name = "employee103")
@Inheritance(strategy=InheritanceType.JOINED)
public class Employee {
@Id
@GeneratedValue(strategy=GenerationType.AUTO)
@Column(name = "id")
private int id;
@Column(name = "name")
private String name;
}
SubClass:
@Entity
@Table(name="regularemployee103")
@PrimaryKeyJoinColumn(name="ID")
public class Regular_Employee extends Employee {
@Column(name="salary")
private float salary;
@Column(name="bonus")
private int bonus;
}
HQL (Hibernate Query Language)
객체 지향 쿼리 언어입니다.
Select 쿼리
Query query = session.createQuery("from Emp");
query.setFirstResult(5);
query.setMaxResult(10);
List list = query.list(); // 5번째부터 10개 레코드 반환
Update 쿼리
Transaction tx = session.beginTransaction();
Query q = session.createQuery("update User set name=:n where id=:i");
q.setParameter("n", "Udit Kumar");
q.setParameter("i", 111);
int status = q.executeUpdate();
System.out.println(status);
tx.commit();
Delete 쿼리
Query query = session.createQuery("delete from Emp where id=100");
// 테이블명이 아닌 클래스명(Emp) 사용
query.executeUpdate();
집계 쿼리
Query q = session.createQuery("select sum(salary) from Emp");
List<Integer> list = q.list();
System.out.println(list.get(0));
HCQL (Hibernate Criteria Query Language)
where, order, limit, offset 절을 프로그래밍 방식으로 작성합니다.
Cache
First Level Cache
- Scope: Session 객체 (애플리케이션에서 여러 세션 사용 가능)
- Default: true
Second Level Cache
- Scope: SessionFactory (전체 애플리케이션에서 사용 가능)
- Default: false
- Second Level Cache 문서
Lazy Collection
자식 객체를 필요할 때 로드합니다.
- Default: true (3.0 버전부터)
<list name="answers" lazy="true">
<key column="qid"></key>
<index column="type"></index>
<one-to-many class="com.javatpoint.Answer"/>
</list>
Transaction Management
try {
session = sessionFactory.openSession();
tx = session.beginTransaction();
// 작업 수행
tx.commit();
} catch (Exception ex) {
ex.printStackTrace();
tx.rollback();
} finally {
session.close();
}
XML 설정
hibernate.cfg.xml
<?xml version='1.0' encoding='UTF-8'?>
<!DOCTYPE hibernate-configuration PUBLIC
"-//Hibernate/Hibernate Configuration DTD 3.0//EN"
"http://hibernate.sourceforge.net/hibernate-configuration-3.0.dtd">
<hibernate-configuration>
<session-factory>
<property name="hbm2ddl.auto">update</property>
<property name="dialect">org.hibernate.dialect.Oracle9Dialect</property>
<property name="connection.url">jdbc:oracle:thin:@localhost:1521:xe</property>
<property name="connection.username">system</property>
<property name="connection.driver_class">oracle.jdbc.driver.OracleDriver</property>
<mapping resource="question.hbm.xml"/>
</session-factory>
</hibernate-configuration>
hbm2ddl.auto=update- 테이블 자동 생성/업데이트mapping resource- XML 매핑 파일 지정mapping class- 어노테이션 클래스 매핑:<mapping class="com.javatpoint.Employee"/>
Collection Mapping (XML)
Key 속성:
<key
column="columnname"
on-delete="noaction|cascade"
not-null="true|false"
property-ref="propertyName"
update="true|false"
unique="true|false"
/>
컬렉션 타입: <list>, <bag>, <set>, <map>
- bag: 인덱스 없음 (순서 랜덤)
- set: bag과 유사하나 유니크
Component Mapping:
별도 테이블 없이 컬럼이 추가되는 방식입니다.
<class name="com.javatpoint.Employee" table="emp177">
<id name="id">
<generator class="increment"></generator>
</id>
<property name="name"></property>
<component name="address" class="com.javatpoint.Address">
<property name="city"></property>
<property name="country"></property>
<property name="pincode"></property>
</component>
</class>
Object Reference Mapping (XML)
Many-to-One:
<class name="com.javatpoint.Employee" table="emp211">
<id name="employeeId">
<generator class="increment"></generator>
</id>
<property name="name"></property>
<property name="email"></property>
<many-to-one name="address" unique="true" cascade="all"></many-to-one>
</class>
One-to-One:
<class name="com.javatpoint.Employee" table="emp212">
<id name="employeeId">
<generator class="increment"></generator>
</id>
<property name="name"></property>
<property name="email"></property>
<one-to-one name="address" cascade="all"></one-to-one>
</class>
