AngularJS Complete Guide

Basic Concepts

Directive

A directive is used as an attribute of a tag to perform some processing.

Example: ng-model

Expression

Use double curly braces to add code between tags:

{{ expression }}

Loading AngularJS Library

<script src="https://ajax.googleapis.com/ajax/libs/angularjs/1.4.8/angular.min.js"></script>

App and Controller Setup

<div ng-app="myApp" ng-controller="myCtrl">
</div>

<script>
var app = angular.module('myApp', []);

app.controller('myCtrl', function($scope) {
});
</script>

Using Code in Attributes

<input style="background-color:{{myCol}}" ng-model="myCol" value="{{myCol}}">

Directives

Basic Directives

Directive	Description
`ng-app`	Application owner
`ng-show`, `ng-hide`, `ng-if`	Show/hide elements (true/false)
`ng-disabled`	Disable element when true
`ng-model`	Bind variable to input tag
`ng-bind`	Bind variable to tag
`ng-init`	Code called during initialization

ng-init Example

<div ng-init="a=1">

ng-repeat Directive

Repeat tags for arrays:

<li ng-repeat="x in names"> {{ x }} </li>

Special variables:

$index: current index
$odd: true if index is odd
$even: true if index is even

For Maps:

<li ng-repeat="(key, value) in map">

ng-options Directive

For select tags (unlike ng-repeat, allows object binding to ng-model):

<!-- String array -->
<select ng-options="x for x in names">

<!-- Object array with label -->
<select ng-options="t.value as t.label for t in selectMessageType">

<!-- Object keys and values -->
<select ng-options="x as y for (x, y) in cars">

ng-switch Directive

<div ng-switch="myVar">
  <div ng-switch-when="dogs">
    <h1>Dogs</h1>
  </div>
  <div ng-switch-when="cats">
    <h1>Cats</h1>
  </div>
</div>

ng-bind-html Directive

Bind innerHTML:

<script src="//ajax.googleapis.com/ajax/libs/angularjs/1.3.15/angular-sanitize.js"></script>
<script>
var app = angular.module("app", ['ngSanitize']);
</script>
<div ng-bind-html="htmlContent"></div>

ng-href and ng-attr-id

<a ng-href="http://www.gravatar.com/avatar/{{hash}}">link</a>
<div ng-attr-id="collapseUssdInformation{{$index}}">

Event Listeners

ng-blur, ng-change, ng-click, ng-copy, ng-cut
ng-dblclick, ng-focus, ng-keydown, ng-keypress, ng-keyup
ng-mousedown, ng-mouseenter, ng-mouseleave, ng-mousemove
ng-mouseover, ng-mouseup, ng-paste

$event Object

<div ng-click="handleClick($event)">

Properties: .clientX, .clientY

Services

Services are added to controllers:

app.controller('myCtrl', function($scope, $location) {
});

$scope Service

Watch model variables:

$scope.$watch('passw1', function() {
    $scope.test();
});

$location Service

$location.absUrl()

$http Service

// GET request
$http.get("welcome.htm").then(function(response) {
    $scope.myWelcome = response.data;
});

// POST request
$http({
    method: 'POST',
    url: '/api/endpoint',
    data: data
}).then(function(response) {
    // success
}, function(response) {
    // error
});

Methods: .delete(), .get(), .head(), .jsonp(), .patch(), .post(), .put()

Response properties:

.config: object used to generate the request
.data: response from the server
.headers: function to get header information
.status: HTTP status number
.statusText: HTTP status string

Filters

Filters change how values are displayed using the pipe symbol:

{{ lastName | uppercase }}

Built-in Filters

Filter	Description
`uppercase`	Convert to uppercase
`lowercase`	Convert to lowercase
`orderBy`	Change order
`currency`	Format as currency
`filter`	Select subset
`date`	Format date

Examples

<!-- Order by country -->
<li ng-repeat="x in names | orderBy:'country'">

<!-- Currency formatting -->
{{ price | currency : "Rupee" : 3 }}

<!-- Filter by object properties -->
<li ng-repeat="x in names | filter : {'name' : 'H', 'city': 'London'}">

<!-- Date formatting -->
<p ng-bind="date | date:'MM/dd/yyyy'"></p>

Custom Filter

app.filter('myFormat', function() {
    return function(x) {
        var txt = "";
        for (var i = 0; i < x.length; i++) {
            var c = x[i];
            if (i % 2 == 0) {
                c = c.toUpperCase();
            }
            txt += c;
        }
        return txt;
    };
});

Custom Directives

Defining a Directive

app.directive("w3TestDirective", function() {
    return {
        template: "I was made in a directive constructor!"
    };
});

Using Custom Directives

<!-- As attribute -->
<div w3-test-directive></div>

<!-- As element -->
<w3-test-directive></w3-test-directive>

<!-- As class -->
<div class="w3-test-directive"></div>

<!-- As comment -->
<!-- directive: w3-test-directive -->

Restricting Usage

app.directive("w3TestDirective", function() {
    return {
        restrict: "A",  // Attribute only
        template: "<h1>Made by a directive!</h1>"
    };
});

Restrict values:

E: Element name
A: Attribute
C: Class
M: Comment
Default: EA

Note: Use camelCase for directive names (myDirective), but dash-separated when invoking (my-directive).

Forms

Input States

<form name="myForm">
    <input type="email" name="myAddress" ng-model="myText" required>

    Valid: {{myForm.myAddress.$valid}}
    Dirty: {{myForm.myAddress.$dirty}}
    Touched: {{myForm.myAddress.$touched}}
</form>

Input field states:

$untouched: field not touched yet
$touched: field has been touched
$pristine: field not modified yet
$dirty: field has been modified
$invalid: field content not valid
$valid: field content is valid

Form states:

$pristine, $dirty, $invalid, $valid, $submitted

CSS Classes

input.ng-invalid {
    background-color: lightblue;
}

Available classes: ng-empty, ng-not-empty, ng-touched, ng-untouched, ng-valid, ng-invalid, ng-dirty, ng-pending, ng-pristine

Custom Form Validation

app.directive('myDirective', function() {
    return {
        require: 'ngModel',
        link: function(scope, element, attr, mCtrl) {
            function myValidation(value) {
                if (value.indexOf("e") > -1) {
                    mCtrl.$setValidity('charE', true);
                } else {
                    mCtrl.$setValidity('charE', false);
                }
                return value;
            }
            mCtrl.$parsers.push(myValidation);
        }
    };
});

Async Validation with $pending

<input type="text" name="userName" ng-model="registration.userName" required is-unique />
<div ng-if="registrationForm.userName.$pending">Checking....</div>

app.directive("isUnique", function($q, $http) {
    return {
        restrict: "A",
        require: "ngModel",
        link: function(scope, element, attributes, ngModel) {
            ngModel.$asyncValidators.isUnique = function(modelValue, viewValue) {
                return $http.post('/username-check', {username: viewValue}).then(
                    function(response) {
                        if (!response.data.validUsername) {
                            return $q.reject(response.data.errorMessage);
                        }
                        return true;
                    }
                );
            };
        }
    };
});

Routing

Setup

<script src="https://ajax.googleapis.com/ajax/libs/angularjs/1.4.8/angular.min.js"></script>
<script src="//ajax.googleapis.com/ajax/libs/angularjs/1.4.8/angular-route.js"></script>

<body ng-app="myApp">
    <a href="#/">Main</a>
    <a href="#red">Red</a>
    <a href="#green">Green</a>

    <div ng-view></div>
</body>

Route Configuration

var app = angular.module("myApp", ["ngRoute"]);

app.config(function($routeProvider) {
    $routeProvider
    .when("/", {
        templateUrl: "main.htm"
    })
    .when("/red", {
        templateUrl: "red.htm"
    })
    .otherwise({
        template: "<h1>Nothing</h1><p>Nothing has been selected</p>"
    });
});

Routes with Controllers

app.config(function($routeProvider) {
    $routeProvider
    .when("/london", {
        templateUrl: "london.htm",
        controller: "londonCtrl"
    });
});

app.controller("londonCtrl", function($scope) {
    $scope.msg = "I love London";
});

Animation

Setup

<script src="https://ajax.googleapis.com/ajax/libs/angularjs/1.4.8/angular-animate.js"></script>
<script>
angular.module('myApp', ['ngAnimate']);
</script>

CSS Transition Example

<div ng-hide="myCheck"></div>

<style>
div {
    transition: all linear 0.5s;
    background-color: lightblue;
    height: 100px;
}
.ng-hide {
    height: 0;
    background-color: transparent;
}
</style>

CSS Animation Example

@keyframes myChange {
    from { height: 100px; }
    to { height: 0; }
}

div.ng-hide {
    animation: 0.5s myChange;
}

Cookies

Setup

<script src="https://cdnjs.cloudflare.com/ajax/libs/angular.js/1.6.1/angular-cookies.js"></script>
<script>
var app = angular.module("app", ['ngCookies']);

app.controller("controller", function($scope, $http, $cookies) {
    // Put Cookie
    $cookies.put("username", $scope.username);

    // Get Cookie
    var user = $cookies.get('username');

    // Remove Cookie
    $cookies.remove('username');
});
</script>

Include

Basic Include

<div ng-include="'myFile.htm'"></div>

Cross Domain Include

app.config(function($sceDelegateProvider) {
    $sceDelegateProvider.resourceUrlWhitelist([
        'http://www.example.com/**'
    ]);
});

Server must include CORS header:

Access-Control-Allow-Origin: *

ng-repeat Multiple Rows

<tr ng-repeat-start="cr in results.crs">
    <td>cell 1</td>
    <td>cell 2</td>
</tr>
<tr ng-repeat-end>
    <td>The Special Cell</td>
</tr>

Application Structure

Multiple Controllers with $rootScope

var app = angular.module('myApp', []);

app.run(function($rootScope) {
    $rootScope.color = 'blue';
});

app.controller('myCtrl', function($scope) {
    $scope.color = "red";  // Overrides rootScope for this controller
});

Separating Files

<div ng-app="myApp" ng-controller="myCtrl"></div>
<script src="myApp.js"></script>
<script src="myCtrl.js"></script>

myApp.js:

var app = angular.module("myApp", []);

myCtrl.js:

app.controller("myCtrl", function($scope) {
    $scope.firstName = "John";
    $scope.lastName = "Doe";
});

Global API

// Object copy
angular.copy($scope.master);

// Utility functions
angular.lowercase()   // Converts string to lowercase
angular.uppercase()   // Converts string to uppercase
angular.isString()    // Returns true if reference is a string
angular.isNumber()    // Returns true if reference is a number

Debugging

Chrome debugging plugin: AngularJS Batarang
